impression X5 IP
The GLP MAD MAXX is the first LED-based fat-beam fixture with an impressive 750 mm beam diameter, comparable to 3kW and 7kW xenon beam lights. Designed for use as a sky beam or super-fat beam effect, it delivers massive light output with no visible external focus points. The CW version (ColorWheel) enables precise color adjustments with a 16-bit color wheel and CTO down to 2500 K. Users can adjust the beam diameter as needed with a virtual iris.
The compact MAD MAXX requires only 2500 W, is IP65-certified, making it weatherproof and low-maintenance. Classified as a “NO LASER” device, it minimizes health risks and regulatory requirements, making it ideal for flexible and safe deployments.
Light Source
| Type | RGBL LED |
| Light Source Count | 19 |
| Light Source Power | 40 W |
| Light Source Lifetime | 50,000 h |
| LED Refresh Rate | Low, Optimal (Default), High 1, High 2, Max |
| CCT | 6,500 K |
| Duv | perfect white point matches with low Duv values |
| CRI (Ra) | 8.000 K: 87 | 6.500 K: 86,7 | 3.200 K: 84,8/td> |
| TLCI | 8.000 K: 90 | 6.500 K: 88,5 | 3.200 K: 74,1 |
Optical System
| Output | up to 11,400 lm |
| Peak Luminous Intensity | 1.8 McD |
| Min. Zoom | 3.6° |
| Max. Zoom | 63° |
| Zoom Ratio | 1:17 |
| Output Lens Diameter | 278 mm |
Effects
| Dimmer | 0 – 100%; 16 bit |
| Shutter | Strobe, Pulse, Sparkel, etc. |
| Color mixing |
RGB RGBL x;y |
| CTC (Color Temperature Control) | 2,500 – 10,000 K |
| CQC (Color Quality Control) |
High Output (HO) High Quality (HQ) Desaturation |
| Magenta/Green-Shift | yes |
| Tungsten Simulation | 8x verknüpft mit festem CCT | 8x relativ zu Colormix |
| Color Wheel | virtual Color wheel, 64 LEE referenced colors |
| Pattern Effects | 50 dynamische Pattern Macros mit Spezialeffekten |
| Pan Movement Angle | 540° normal, 16 bit |
| Pan/Tilt Movement Speed | super fast |
Control
| DMX channels | M1: CH24 / M2: CH35 / M3: CH41 / M4: CH89 / M5: CH70 / M6: CH89 |
| Control Modes | 6 |
| Protocol |
DMX (USITT DMX512-A) RDM (ANSI/ESTA E1.20) Art-Net sACN iQ.Mesh included: Lumenradio CRMX @ FPO |
| Setting and addressing |
control panel with backlit graphic display 4 Button Menu Navigation DMX RDM iQ.Service App NFC via iQ.Service App |
| Software Update |
DMX link via DProg iQ.Mesh |
| High-Res Channels |
Intensity Pan Tilt Colormix |
| Performance Modes |
fast normal (balanced) smooth |
| Dimming Curves |
linear soft S-Curve |
| Fan Modes |
regulated high medium low minimum |
| Subfixture Mode |
Normal independent |
| White points | 8.000 K; 5.600 K; 4.200 K; 3.200 K |
| Others |
Stand Alone 1 captured Scene Art-Net/sACN Node Data Conversion iQ.Mesh FPO (Flexible Protocol Option) |
Connectors
| Signal connection |
XLR 5-Pin In/Out Neutrik etherCON port A & B (failsafe) GLP FX.Port |
| Power input | Neutrik powerCON TRUE1 In/Out |
Electrical Specifications
| Power input |
100 – 240 VAC / 50 – 60Hz/td> |
| Power supply | auto-ranging electronic switch-mode |
| max. power (@230V) | 750 W |
Thermal Specifications
| Cooling | combined convection and forced air |
| max. surface temperature (Ta = 40°C) | 45 °C / 115 °F |
| min. ambient temperature (Ta min.) | 5 °C / 40 °F |
Mounting Options
| Mounting |
2 pair of 1/4-turn locks M10 Screw Thread(s) eyelets for safety cable |
| Orientation | any |
| Location | Indoor permanent Outdoor temporary |
Construction
| Housing Color | Black |
| Housing Material |
high-impact flame-retardand thermoplastic Aluminum steel metal plates |
| Protection Rating | IP 65 |
| Construction Features | Tilt-Lock-System prepared for external accessories |
Dimensions & Weight
| Height (head vertical) | 530 mm / 20.87 in |
| Width (across yoke) | 377 mm / 14.84 in |
| Diameter | 324 mm / 12.76 in |
| Weight | preliminary: 21 kg / 46 lbs |
