impression X5 IP Maxx
The GLP impression X5 IP Maxx delivers an extraordinary luminous flux of up to 24,000 lumens, with an expanded colour space, from 37 powerful 40-watt RGBL LEDs.
Equipped with the new iQ.Gamut colour algorithm, the impression X5 IP Maxx generates a clean white point with a CRI 90 / TLCI 90 at 6,500 Kelvin. It also offers the option of quickly switching to other fixed colour temperatures, all of which are precisely calibrated to the colour temperature curve, while still offering a colour quality of CRI 85 / TLCI 75 even with warm white light of 3,200 Kelvin.
With the new 16:1 zoom mechanism, the impression X5 IP Maxx delivers up to 3.3 Mcd light intensity, a penetrating 3.5° parallel beam and up to 60° homogeneous wash light. The new, circular lens design offers a modern look, while additional fantastic looks can be generated using individual pixel control with pixel mapping and integrated dynamic pattern effects.The impression X5 IP Maxx comes with an extensive feature and effects package, including a virtual colour wheel with access to 64 colours from the LEE filter palette, new colour quality control, magenta/green correction, a tungsten simulation and effects channel and a 2-layer effect option.Thanks to the IP65 certification, the fixture can be used both indoors and outdoors in any weather. The compact design, with a weight of less than 30 kg, is designed for easily installation in standard pre-rig truss systems. The impression X5 IP Maxx can be controlled via DMX, ArtNet, sACN and LumenRadio CRMX. It also has NFC and the iQ.Mesh module for convenient configuration via the GLP iQ.Service app.
Light Source
| Type | RGBL LED |
| Light Source Count | 37 |
| Light Source Power | 40 W |
| Light Source Lifetime | 50,000 h |
| LED Refresh Rate | Low, Optimal (Default), High 1, High 2, Max |
| CCT | 6,500 K |
| Duv | perfect white point matches with low Duv values |
| CRI (Ra) | 6,500 K: 90 | 3,200 K: 85 |
| TLCI | 6,500 K: 90 | 3,200 K: 75 |
Optical System
| Output | up to 24,500 lm |
| Peak Luminous Intensity | 3.33 Mcd |
| Min. Zoom | 3.5° |
| Max. Zoom | 65° |
| Zoom Ratio | 1:19 |
| Output Lens Diameter | 380 mm |
Effects
| Dimmer | 0 – 100%; 16 bit |
| Shutter | Strobe, Pulse, Sparkel, etc. |
| Color mixing | RGB RGBL x;y |
| CTC (Color Temperature Control) | 2,500 – 10,000 K |
| CQC (Color Quality Control) | High Output (HO) High Quality (HQ) Desaturation |
| Magenta/Green-Shift | yes |
| Tungsten Simulation | 8x linked to fix CCT | 8x relative to Colormix |
| Color Wheel | virtual Color wheel, 64 LEE referenced colors |
| Pattern Effects | 50 dynamic pattern macros with special effects |
| Pan Movement Angle | 540° normal (650° extended), 16 Bit Resolution |
| Tilt Movement Angle | 240°, 16 Bit Resolution |
| Pan/Tilt Movement Speed | super fast |
Control
| DMX channels | M1: CH22 / M2: CH33 / M3: CH42 / M4: CH141 / M5: CH123 / M6: CH160 |
| Control Modes | 6 |
| Protocol | DMX (USITT DMX512-A) RDM (ANSI/ESTA E1.20) Art-Net sACN iQ.Mesh optional: Lumenradio CRMX @ FPO |
| Setting and addressing | control panel with backlit graphic display 4 Button Menu Navigation DMX RDM iQ.Service App NFC via iQ.Service App |
| Software Update | DMX link via DProg iQ.Mesh Fixture2Fixture Push |
| High-Res Channels | Intensity Pan Tilt Colormix |
| Performance Modes | fast normal (balanced) smooth |
| Dimming Curves | linear soft S-Curve |
| Fan Modes | regulated high medium low off |
| Subfixture Mode | Normal independent |
| White points | 8,000 K; 5,600 K; 4,200 K; 3,200 K |
| Others | Stand Alone 1 captured Scene Art-Net/sACN Node Data Conversion iQ.Mesh FPO (Flexible Protocol Option) SW Fixture2Fixture Push |
Connectors
| Signal connection | XLR 5-Pin In/Out Neutrik etherCON port A & B (failsafe) |
| Power input | Neutrik powerCON TRUE1 In/Out |
Electrical Specifications
| Power input | 100 – 240 VAC / 50 – 60Hz |
| Power supply | auto-ranging electronic switch-mode |
| Power supply cable | US: 16 A, 14 AWG, UL listed, E304117, SJT, 4.9 ft EU: 16 A, 1.5 mm², H05VV-F, 1.5 m |
| max. power (@230V) | 1,500 W |
Thermal Specifications
| Cooling | combined convection and forced air |
| max. surface temperature (Ta = 40°C) | 45 °C / 115 °F |
| min. ambient temperature (Ta min.) | 5 °C / 40 °F |
| Total heat dissipation (calculated, +/-10%) | 5,120 BTU/hr |
Mounting Options
| Mounting | 2 pair of 1/4-turn locks 2 eyelets for safety cable M10 Screw Thread(s) |
| Orientation | any |
| Location | Indoor permanent Outdoor temporary |
Construction
| Housing Color | Black |
| Housing Material | high-impact flame-retardand thermoplastic Aluminum steel metal platess |
| Protection Rating | IP 65 |
| Construction Features | baseless design Tilt-Lock-System prepared for external accessories (Egg Crate; Tubus, etc) |
Dimensions & Weight
| Height | 631 mm / 24.8 in |
| Width (across yoke) | 483 mm / 19 in |
| Length | 358 mm / 14.1 in |
| Weight | 30 kg / 77.2 lbs |
