The Exo Wash 30 from FUSION by GLP is an IP65 rated Moving Head wash fixture with a full feature set in a compact housing. Featuring a durable and robust die cast housing, the Exo Wash 30 is ready for the toughest of outdoor weather conditions.
Product details
FUSION Exo Wash 30
The Exo Wash 30 from FUSION by GLP is an IP65 rated Moving Head wash fixture with a full feature set in a compact housing.
Lumenradio CRMX DMX/RDM (optional)
Wireless
4°
Min. Zoom
IP 65
Protection Rating
521 mm / 20.5 in
Height (head vertical)
1 / 5
Why this product
FUSION Exo Wash 30
With 7 powerful 32 W RGBW Osram LEDs, the FUSION Exo Wash 30 delivers a solid, bright beam in a full color range from the deepest saturates to the lightest pastel shades, and offers color control over each individual pixel.
Supporting the stunning output is a zooming optical system that can vary the beam continuously from 4° to 45°.
The Exo Wash 30 incorporates True1 In/Out connectors, variable PWM control and also features easy to use magnetic head mounts, for filter holders and any other future attachments.
The Exo Wash 30 from FUSION by GLP is an IP65 rated Moving Head wash fixture with a full feature set in a compact housing.
Featuring a durable and robust die cast housing, the Exo Wash 30 is ready for the toughest of outdoor weather conditions. With 7 powerful 32 W RGBW Osram LEDs, the FUSION Exo Wash 30 delivers a solid, bright beam in a full color range from the deepest saturates to the lightest pastel shades, and offers color control over each individual pixel.
Supporting the stunning output is a zooming optical system that can vary the beam continuously from 4° to 45°.
The Exo Wash 30 incorporates True1 In/Out connectors, variable PWM control and also features easy to use magnetic head mounts, for filter holders and any other future attachments.
Light Source
- Type
- RGBW
- Light Source Count
- 7
- Light Source Power
- 40 W
- Light Source Lifetime
- 20,000 h
Optical System
- Min. Zoom
- 4°
- Max. Zoom
- 54°
Effects
- Dimmer / Shutter
- 0 – 100% electronicregular and random strobe and pulse effects
- Color mixing
- RGBWvariable 0 – 100 %
- CTC (Color Temperature Control)
- 2,500 – 10,000 K
- Pan
- 540°
- Tilt
- 267°
Control
- DMX channels
- 13 / 22 / 37 / 50
- Control Modes
- 4
- Control Modes
- Pixel-Mapping
- Protocol
- DMX (USITT DMX512-A)RDM (ANSI/ESTA E1.20)
- Setting and addressing
- RDM
- Display
- self charging buffer batteryOLED display with 4 buttons
- Wireless
- Lumenradio CRMX DMX/RDM (optional)
- Software Update
- DMX link
- Dimming Curves
- linearsoft
- Fan Modes
- regulatedhighmediumlow
Connectors
- Signal connection
- XLR 5-PinIn/Out
- Power input
- Neutrik powerCON TRUE1In/Out
Electrical Specifications
- Power input
- 100 – 240 VAC / 50 – 60Hz
- Power supply
- auto-ranging electronic switch-mode
- Fuse
- T5A 250 V
- max. power (@230V)
- 230 W, 1 A
Thermal Specifications
- Cooling
- combined convection and forced air
- max. ambient temperature (Ta max.)
- 45 °C / 113 °F
- min. ambient temperature (Ta min.)
- -20°C / -4°F
- Total heat dissipation (calculated, +/-10%)
- 785 BTU/hr
Mounting Options
- Mounting
- 2 pair of 1/4-turn locksRubber feeteyelets for safety cable
- Orientation
- any
- Location
- Outdoor temporary
- min. distance to combustible materials
- 0.5 m / 18.7 in
Construction
- Housing Color
- Black
- Housing Material
- Aluminum
- Protection Rating
- IP 65
- Construction Features
- Pan-Tilt-Lock-System
Dimensions & Weight
- Height (head vertical)
- 521 mm / 20.5 in
- Width (across yoke)
- 380 mm / 14.96 in
- Length
- 279 mm / 11 in
- Weight
- 19.7 kg / 43.43 lbs
ManualEXO Wash 30 User Manual EN Rev B ( pdf | 4.19 MB)
Download ↗
DMXEXO Wash 30 DMX Channel Index EN Rev A FINAL ( pdf | 812.03 KB)
Download ↗
CADFUSION EXO Wash 30 CAD Rev20230310-1 ( zip | 4.55 MB)
Download ↗
PhotometricsFUSION Exo Wash 30 Photometrics Rev20210715-1 ( zip | 610.65 KB)
Download ↗
Fixture LibrariesEXO Wash 30 Fixture Library ( zip | 2.98 KB)
Download ↗
Flyer / InfoFUSION Exo Wash 30 Cut Sheet EN ( pdf | 861.76 KB)
Download ↗
Flyer / InfoExo Wash 30 Data Sheet EN ( pdf | 1.45 MB)
Download ↗
